Technical Specifications
10
6 Technical Specifications
Table 4 lists the technical specifications:
Table 4: Technical Specifications
1
INPUTS:
of the WP-500
1 composite video (1Vpp/75
Ω) on an RCA connector
2 VGA (PC) on 15-pin HD connectors
2 stereo analog audio on 3.5mm mini connectors
1 unbalanced audio on 2 RCA connectors
1 condenser/dynamic microphone on a 3.5mm mini connector
OUTPUTS (on Terminal
Block Connectors): 1 VIDEO OUT 2-pin, 2 Audio OUT 3-pin unbalanced stereo audio, 1 VGA (PC)
OUTPUT 10-pin
PORTS: Ethernet, 1 IR out on terminal block connectors, 1 RS-232 on terminal block
connectors, 1 USB connector
DEFAULT IP ADDRESS 192.168.1.39
SUPPORTED BAUD
RATES FOR RS-232: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
DEFAULT EDID
INFORMATION: Standard timings supported: 640x480px60Hz (IBM VGA), 640x480px67Hz
(Apple Mac II), 640x480px72Hz (VESA), 640x480px75Hz (VESA),
800x600px56Hz (VESA), 800x 600px60Hz (VESA), 800x600px72Hz (VESA),
800x600px75Hz (VESA), 1024x768px60Hz
2
POWER SOURCE:
(VESA), 1024x768px70Hz (VESA),
1024x768px75Hz (VESA), 1280x1024px75Hz (VESA), 1280x1024px60Hz
(VESA STD), 1280x960px60Hz (VESA STD), 1400x1050px60Hz (VESA STD),
1440x900px60Hz (VESA STD), 1600x1200px60Hz (VESA STD)
12V DC, 180mA
FUSE: 500mA, FSMD 1812
ADAPTER: 12V, 5A
DIMENSIONS: 16.2cm x 3.4cm x 11.4cm (6.37" x 1.34" x 4.49", W, D, H)
WEIGHT: 0.14kg (0.31lbs) approx.
ACCESSORIES: Power supply, screwdriver, Kramer K-Config Windows®-based configuration
software
OPTIONS: 12V DC, 0.5A Power supply
3
, USB cable 3' (0.91m)
4
, WP-500 Installation
cable, FC-200 XGA EDID Copier, Site-CTRL™ Management Tool Software
1 Specifications are subject to change without notice
2 Native/preferred timing (4:3)
3 Model number AD2512C, part number 2535-000251
4 Part number C-UA/MUB-3
