Using Your WP-500
9
9
5.2 Operating the WP-500
The Ethernet and USB ports are used to configure the WP-500 front panel
SELECT buttons
1
to perform several tasks
2
Table 3
, such as those defined in the example
in . Pressing a button initiates a macro sequence
3
Table 3: A Configuration Setup Example
, during which the button
blinks (as programmed by the system integrator).
The Label Macro Sequence Example
ON/OFF • Power up/Power down the projector 4
• Set required Audio level for the projector
• 1 minute delay [for the projector to heat up]
• The projector selects the PC input
PC 1 • Select the PC 1 input of the projector
• Stop the DVD player
• Power down the DVD player
PC 2 • Select the PC 2 input of the projector
• Stop the video player
VIDEO (CV) • Select the VIDEO (CV) input
• The projector selects the DVD input
• Play the DVD
In addition to operation via the front panel buttons, you can monitor the WP-500
via the Ethernet, using Site-CTRL™ and the stored Web pages.
1 By the technical installer
2 A macro sequence, including several commands per button, carried out one after the other
3 The macro sequence can be carried out instantly or can take a while, depending on the delay times included in the sequence
4 This is a two toggle button. a macro can be assigned for each toggle of the button via the Kramer K-Config software
