4 RC-76R/RC-78R - Overview
3 Overview
The RC-76R/RC-78R are highly versatile master room controllers that act as an
all-in-one extended remote control panel for control of AV equipment
—especially
projectors and associated equipment
—in any room (such as classrooms,
boardrooms, or auditoriums). They streamline operations and simplify control by
integrating audio, video, and computer-video sources into a centralized system.
The RC-76R/RC-78R have identical functionality. The RC-76R has six buttons and
the RC-78R has eight buttons.
The RC-76R/RC-78R features:

6/8 configurable, RGB backlit, front panel buttons, configured using the
K-Config configuration software
Available from Kramer Electronics on our Web site at
http://www.kramerelectronics.com/support/?soft=k-config .

1 general purpose I/O port that can be configured by K-Config as a digital
input, digital output or analog input for interfacing with a variety of devices
such as sensors, switches, LEDs, or relays

2 bidirectional RS-232 ports that can control AV equipment such as
projectors, LCD and PDP displays, power amplifiers, switchers and scalers

2 relay contact closure ports that can control other room items related to the
AV system, such as, raising and lowering drapes, a screen or a projector

2 IR control ports with an IR learning receiver behind the front plate that
learns commands from any IR remote

1 RS-485 control port

Compatibility with Kramer Site-CTRL software for network remote control
and management over the Ethernet port

A K-NET ™ control channel that connects compatible user interfaces, supply
power and control data over a single cable

Flexible control via Ethernet and K-NET

Decora compatible, wall plate size of 1 gang US
