RC-76R/RC-78R - Connecting the RC-76R/RC-78R 7
4 Connecting the RC-76R/RC-78R
Always switch off the power to each device before connecting it to your
RC-76R/RC-78R. After connecting your RC-76R/RC-78R, connect its
power and then switch on the power to each device.
To connect the RC-76R/RC-78R as illustrated in the example in Figure 2 :
1. Connect the IR outputs as follows:

Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the
DVD player 1
 Connect an IR emitter to IR OUTPUT 2 and attach the emitter to the
DVD player 2
2. Connect the RS-232 ports (see Section ‎4.1 ) as follows:
 Connect RS-232 port 1 to the projector
 Connect RS-232 port 2 to the plasma display
3. Connect the RELAY terminal block connectors as follows:
 Connect RELAY C and 1 to the screen
 Connect RELAY C and 2 to the lighting system
4. Connect the GPI/O 1 port to a motion detector.
5. Connect the Ethernet port to a network.
