4 RC-76M/ RC-712M - Overview
3 Overview
The RC-76M and RC-712M are six and twelve−button configurable room
controllers for multimedia rooms. They control audio components, video
components and other room facilities such as lights and screens. They are
designed to be installed in compatible Merten System M on-wall boxes (frame and
housing).
RC-76M/RC-712M features:

6/12 configurable buttons - RGB backlit, front panel buttons, configured
using the K−Config configuration software

1 GPI/O port that c an be configured by K−Config configuration software as a
digital input, digital output or analog input for interfacing with a variety of
devices such as sensors, switches, LEDs, or relays

Kramer Site-CTRL compatibility for network remote control and management
over the Ethernet port

2 bidirectional RS-232 ports for the control of AV equipment such as
projectors, LCD and PDP displays, power amplifiers, switchers and scalers

2 relay contact closure ports for the control of other room items related to an
AV system, such as, raising and lowering drapes, a screen or a projector

2 IR control ports with an IR learning receiver on the front panel that learns
commands from any IR remote

1 RS-485 port

A K- NET™ control channel that connects compatible user interfaces,
supplies power and controls data over a single cable

A USB port located on the front panel to connect to a computer for firmware
upgrade or for uploading the configuration file

Flexible control - via Ethernet
and K−NET

Wall Plate Size - 2 gang EU, Merten compatible
