RC-76M/ RC-712M - Technical Specifications
7
Technical Specifications
PORTS:
2 RS-232, 1 RS-485, 1 GPI/O and 1 K-NET on terminal
block connectors; 1 Ethernet on an RJ-45 connector;
1 USB for programming
OUTPUTS:
2 IR, 2 relays (36V AC or DC, 2A, 60VAC maximum on
non-inductive load)
DEFAULT IP SETTINGS:
IP number
192.168.1.39; Mask
– 255.255.0.0;
Gateway
– 0.0.0.0
POWER CONSUMPTION:
12V DC, 1.25A
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
7.9cm x 2.8cm x 12.4cm (3.1" x 1.1
” x 4.9") W, D, H
(with wall plate)
WEIGHT:
0.245kg (0.54lbs) approx.
ACCESSORIES:
Power supply, button caps, button labels
OPTIONS
Merten-compatible 2 gang on-wall box (housing and
frame, P/N: OWB-2G/M)
Specifications are subject to change without noti
