Technical Specifications
13
2. Select the required COM Port 1 .
3. Click the File button to select the .s19 firmware file included in the package.
4. Click the Send button to download the file. The Send button lights red.
5. Wait until downloading is completed and the red Send button turns off.
6. Disconnect the power on the
RC-8IR.
7. Set the PROGRAM switch to OFF.
8. Connect the power on the
RC-8IR.
6.4 Installing the Web Applet
2
Follow these steps to install the Web Applet:
1. Connect RC-8IR to your PC through computer networking.
2. Start RC Configuration Software and connect to the RC device (see the RC
Configuration and Installation Guide3).
3. In the Device menu select Upgrade Applet option and browse to MC.dat file
included in the package
4. Wait until uploading is completed and the success message appears. Click
OK.
7 Technical Specifications
Table 6 defines the technical specifications:
Table 6: Technical Specifications
4
of the Universal Room Controller Series
PORTS: 2 RS-232 on terminal block connectors; 1 RS-485 on terminal block
connectors; 1 ETHERNET RJ-45 port
OUTPUTS: 2 relays on terminal block connectors (36V AC or DC, 2A, 60VAC maximum on
non-inductive load); 2 IR emitters on terminal block connectors
POWER SOURCE: 12V DC, 155mA
DIMENSIONS: 11.4cm x 4.3cm x 6.9cm (4.49" x 1.70" x 2.72", W, D, H)
WEIGHT: 0.3 kg (0.67 lbs.) approx
ACCESSORIES: Kramer 3.5mm to IR Emitter Control Cable (C-A35/IRE-10), power supply, two
extra M3x5 screws, Java based control software (internal), Windows®-based
Kramer control software
OPTIONS: Kramer 3.5mm to IR Emitter Control Cable (C-A35/IRE-10), 15 meter and 20 meter
IR emitter extension cables
1 To which the RC device is connected on your PC
2 This section is applicable only to firmware version 26.0 and higher and requires RC Configuration Software version
1.26.0.38 and higher
3 On our Web site at http://www.kramerelectronics.com
4 Specifications are subject to change without notice
