PL-18 Commands in Protocol 3000
9
9
Emit via serial port 1 four bytes – the binary representation of P2000 “all-in 2” serial command:
Using the binary port to send binary data:
#bin uart, 1, 4 “[" $01 $82 $80 $81 "]"
Emit via IR port 2 forty-two bytes – the binary representation of Kramer signal “button-1”:
#bin ir, 2, 42 “[" $FF $01 $8F $69 $67 $65 $66 $69 $66 $6C $63 $66 $C9 $68 $C8 $66 $CB $66 $C8
$CE $FF $01 $BC $69 $66 $66 $C8 $69 $66 $69 $66 $66 $66 $69 $66 $69 $65 $67 $65 $FF $EF $26 "]"
U
Using the binary port to receive and convey binary data:
Convey four binary bytes received on serial port 1 – these four binary bytes are the binary representation of the
P2000 “all-in 2” serial command:
#rbin uart, 1, 4 “[" $01 $82 $80 $81 "]"
8.2
12B
Help Commands
Command Syntax Response
Protocol handshaking #CR ~OKCRLF
8.3
13B
Result and Error Codes
Result/Error Syntax
Command ran successfully, no error. COMMAND PARAMETERS OK
Protocol Errors:
Syntax error ERR001
Command not available for this device ERR002
Parameter is out of range ERR003
Unauthorized access (command run without the matching
login).
ERR004
8.4
14B
Identification Commands
Command Syntax Response
Protocol handshaking #CR ~OK CRLF
Read device model MODEL? MODEL MACHINE_MODEL
Read device serial number SN? SN SERIAL_NUMBER
Read device firmware
version
VERSION? VERSION MAJOR .MINOR .BUILD .REVISION
Set machine name NAME MACHINE_NAME NAME MACHINE_NAME RESULT
Read machine name NAME? NAME MACHINE_NAME
Reset machine name to
factory default*
NAME-RST
NAME-RST MACHINE_FACTORY_NAME
RESULT
Visual identification IDV IDV OK
*Note: The machine name is not the same as the model name. The machine name is used to identify a specific
machine or a network in use (with DNS feature on).
MACHINE_NAME = Up to 14 alphameric chars.
* Machine factory name = Model name + last 4 digits from serial number.
