U2121A-101 Operating Guide 15
[1] SL1 to SL5 refers to the 8762/3/4 and 8765x-324 RF switch connectors for Ch1 to Ch5.
[2] X1 to X5 refers to the 8765x-024 RF switch connectors for Ch1 to Ch5.
[3] SV1 to SV5 refers to the N181x RF switch connectors for Ch1 to Ch5.
[4] X7 refers to the connector for general I/O on the switch driver board.
[5] X8 refers to the connector for general output on the switch driver board.
[6] X9 refers to the connector for general input on the switch driver board.
D. Launch the Agilent U2121A-Based RF Switch Driver
Software
1 Before attempting to start- up your U2121A- Based RF Switch Driver
Software, it is recommended to follow the step- by- steps
instructions below.
2 Plug in your instrument via the supported USB socket.
3 Go to Start > All Programs > Agilent IO Libraries Suite > Agilent Connection
Expert to launch the Connection Expert.
4 The detected U2121A will be visible on the Instrument I/O on this PC
explorer pane. Right- click on the U2121A instrument on the
explorer pane.
5 A context menu will appear as shown below. Select Send Commands
To This Instrument.
WA RN I N G
The total allowable current is 1500 mA. Please ensure that the total current
consumption is not more than 1500 mA.
N O T E
Before you proceed, ensure that your system meets the minimum system
requirements.
