U2121A-101 Operating Guide
5
Product at a Glance
Product outlook
Top view (without casing)
Connector for
general I/O
Connector for
general output
Connector for
general input
DC power jack
Power
Digital IO
Connector for
rating
terminal
N181x RF switches
Connector for
Connector for 8762/3/4
8765x-024 RF switches
8765x/324 RF switches
