Technical Specifications
17
17
8 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications
1
INPUTS:
of the VS-81HD 8x1 HD/SD-SDI Switcher
8 SDI SMPTE-259M, 292M, 344M serial video, 75 ohms on BNC connectors
1 GENLOCK 75
Ω / Hi-Z on looping BNC connectors, bi-level, Tri-level inputs
OUTPUTS: 2 identical equalized and reclocked SMPTE-259M, 292M, 344M outputs 75
Ω
on BNC connectors
1 GENLOCK 75
Ω / Hi-Z on looping BNC connectors, bi-level, Tri-level inputs
MAX. OUTPUT LEVEL: 800mVpp /75
Ω
JITTER: Better than 0.2UI
DATA RATE: Up to 1.485Gbps
CONTROLS: Front-panel, RS-232; RS-485, ETHERNET, infrared remote, dry contact, and
panel lock
POWER SOURCE: Universal, 100-240VAC, 50/60Hz 22VA
DIMENSIONS: 19 inch (W), 7 inch (D), 1U (H) rack mountable
WEIGHT: 1.5kg (3.3lbs) approx.
ACCESSORIES: Power cord, Null-modem adapter, external remote IR receiver cable
2
1 Specifications are subject to change without notice
2 P/N: C-A35M/IRR-50
