# Feature Function
35 DISPLAYPORT Connect to the DisplayPort source
36
VIDEO
OUTPUT
Connectors
PC 15-pin HD Connect to a computer graphics acceptor
37 HDMI Connect to an HDMI acceptor
38 DGKAT RJ-45 Connect to a DGKat receiver (for example, Kramer PT-572+)
39 RS-232 9-pin D-sub Port Connect to the PC or other serial controller
40 ETHERNET Connector Connects to the PC or other Controller through computer networking
41 REMOTE Terminal Block Connectors For remotely switching the inputs and PIP input via contact closure switches
42 Power Connector with Fuse AC connector, enabling power supply to the unit
43 POWER Switch Switch for turning the unit ON or OFF
