Connecting the VP-747T
11
7 Connecting the VP-747T
To connect the VP-747T to up to four VP-747 machines, as the example in
Figure 7 illustrates, do the following
15F
1
:
1. Connect the “TO VP-747” mini XLR connector of the VP-747T (by
one-to-one connection) to the VP-747, as follows:
 MACH. # 1 to the mini XLR connector of the VP-747 which will be
recognized as machine # 1
 MACH. # 2 to the mini XLR connector of the VP-747 which will be
recognized as machine # 2
2. Connect the “TO VP-747” 3-pin terminal block ports of the VP-747T (by
wired connection) to the VP-747, as follows (see section
U
7.2
U
):
 MACH. # 3 to the mini XLR connector of the VP-747 which will be
recognized as machine # 3
 MACH. # 4 to the mini XLR connector of the VP-747 which will be
recognized as machine # 4
3. Set the “T-Bar Optimization” mode in the “Transition” menu of the
VP-747 to On.
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not illustrated in
U
Figure 7
U
).
If you want to control several units simultaneously, press the MACHINE #
button until the letter A is selected in the 7-segment LED display (A=ALL).
One of the units must be connected to port #1 for units to be controlled
simultaneously.
1 Switch OFF the power on each device before connecting it to your VP-747T. After connecting your VP-747T, switch on its
power and then switch on the power on each device
