VP-747 Control Software - Defining the Control Software 7
Main Window Features
#
Feature Function
8 Take Button Pressing TAKE causes the transition to occur
The effect is only seen when watching the program
output. The preview screen blanks during the transition
9 Advanced Button Click to open a list of transition parameters, see
10
Section
3.4
Transition Mode
Buttons
Click to choose screen-to-screen transitions
3.1 Defining the Menu Bar
The following table describes the Controller Software menu bar options.
Menu Sub Menu 1 Sub Menu 2 Description
Device Connect/
Disconnect
Connects or disconnects the controlled
device
Factory reset Returns the device to its preset default
settings
Refresh Refreshes the information on the screen
Panel Lock Prevents tampering with the front panel
buttons. Settings: On/Off
Panel Save
Lock
Select On or Off
Set to ON to save the lock status when
the machine is powered down
Panel Input
Lock
Select On or Off
Set to OFF so you can still use the
SOURCE buttons on the front panel
even when the lock button is on
TCP/IP For setting the IP address, subnet
mask, gateway and DHCP
After changing the IP address the unit
disconnects and it must be reconnected
with the new IP address
Baud rate 9600, 115200
After changing the baud rate the unit
disconnects and it must be reconnected
using the new baud rate
Preview
and
Program
Presets Full. PIP, Pic plus Pic, Split
Output
Resolution
Choose from 43 resolutions, native and
4 custom
Selected Input
Properties
Source Type RGBHV, RGBS(PC), RGsB(PC),
RGBS(video), RGsB(video), YCbCr,
Y/C, Video, HDMI
Video Standard Sets the video source standard: Auto,
NTSC, PAL, PAL-M, PAL-N, NTSC
4.43, SECAM, PAL 60
H-Position Sets the horizontal position of the
display: 0-1000
V-Position Sets the vertical position of the display:
0-1000
Frequency Sets the frequency for UXGA inputs:
0-50
Phase Sets the input phase: 0-31
