30 VP-730 - Configuring the VP-730 via the OSD MENU Screens
7.7 The Setup Screen
Figure 20: Setup Screen
Setting Function Default
Save Saves up to eight profiles from 1 to 8
Recall Recalls a profile from 1 to 8
Slideshow Set the speed for the slide show to Min, Low, Mid, Long, Max or
Off (see Section 7.7.1 )
Min
Frame Lock Locks the vertical refresh rate of the output to that of the input.
Set to On or Off.
Note that seamless switching is not possible when working in the
Frame Lock mode unless all sources are frame synchronized.
In cases where the output resolution can support the vertical
refresh rate of the input, the output refresh rate will change
according to the input refresh rate
Off
Auto Image Automatically adjusts and aligns the picture each time one of the
UXGA inputs is selected or if the UXGA input resolution has
changed. Set to Manual or Auto
Manual
Switching
Mode
Selects seamless switching (fade-through-Black) or Fast
switching which is faster but may cause glitches on the output
(applies when switching between analog inputs)
Seamle
ss
Factory
Reset
Select Yes to reset your VP-730 to its preset default settings
Advanced
Setup
Opens the advanced setup menu screen (see Figure 21 ), which
includes the: Mode Set, OSD, Misc, Input and Output OSD
menus ( Section 7.8 )
EDID
EEPROM
Protect
Set to On or Off
Set to On to lock the EEPROM and protect the EDID memory by
not allowing to make deliberate changes
HDMI Hot
Plug
Set /On or /Off
Set to On for sources with HDCP. When in Normal operation, the
unit sends a hot plug to the source for any Group/Scaler
switching request.
Normal
