4 SID-X1 - Overview
3 Overview
The SID-X1 accepts an HDMI, DisplayPort, DVI and PC graphics video input, as
well as an unbalanced stereo audio input (which is embedded into the output
signal), and transmits the signal via TP (Twisted Pair) cable to a compatible
switcher (for example, the
VP-81SID). When the SID-X1 is connected to a
switcher, it also controls the input and output selection of the switcher.
In particular the SID-X1:
• Supports DDC (Display Data Channel) communication between the selected
input and output on 15-pin HD connector pins 12 and 15
• Supports HDMI with Deep Color, x.v.Color™ and 3D
• Is HDCP compliant—works with sources that support HDCP repeater mode
• Can be installed up to 50m (164ft) from the switcher
• Features automatic live input detection when connected to a single input
• Lockable EDID
You can control the SID-X1 using the front panel buttons, or remotely via contact
closure switches.
