SID-X1 – Contents i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Shielded Twisted Pair/Unshielded Twisted Pair 3
2.3 Recycling Kramer Products 3
3 Overview 4
4 Defining the SID-X1 Step-in Commander 5
5 Connecting the SID-X1 7
5.1 Connecting the Remote Step-In Switch and LED 8
5.2 Connecting the Remote Select Switch and LED 9
5.3 Connecting the Remote Input Selection LEDs 10
5.4 Audio Mode Selection 11
5.5 Locking the EDID 11
6 Operating the SID-X1 12
6.1 Selecting an Input 12
6.2 Taking Control of the Switcher Input 12
6.3 Audio Stream Priority 12
7 Wiring the Twisted Pair RJ-45 Connectors 13
8 Technical Specifications 14
9 Default EDID 15
9.1 HDMI, DisplayPort and DVI 15
9.2 PC-UXGA 16
Figures
Figure 1: SID-X1 Step-in Commander Front Panel 5
Figure 2: SID-X1 Step-in Commander Rear Panel 6
Figure 3: Connecting the SID-X1 Step-in Commander 7
Figure 4: REMOTE STEP-IN Switch and LED Wiring 8
Figure 5: REMOTE SELECT Switch and LED Wiring 9
Figure 6: Remote Input Indicator LED Wiring 10
Figure 7: Example Remote Input Indicator LED Wiring for the DVI Input 10
Figure 8: TP Pinout Wiring 13
