Connecting the TP-210 XGA Line Transmitter/DA
8
6 Connecting the TP-210 XGA Line Transmitter/DA
To connect the TP-210, as Figure 3 illustrates, do the following:
1. Connect an XGA source (for example, a computer graphics source) to the
XGA INPUT connector.
2. Connect the XGA OUT 1 XGA connector to an XGA acceptor (for
example, local display 1).
3. Connect the XGA OUT 2 XGA connector to an XGA acceptor (for
example, local display 2).
4. Connect
1
the 10 LINE OUTPUT CAT 5 connectors (from 1 to 10) to the
LINE IN CAT 5 connectors of 10 XGA line receivers (for example, the
Kramer
2
TP-120).
5. Connect the power cord
3
(not shown in Figure 3 ).
1 You do not have to connect all the LINE OUTPUTS
2 Alternatively, you can use a different Kramer receiver, for example, the Kramer PT-120
3 We recommend that you use only the power cord that is supplied with this machine
