Your TP-112HD XGA/HD Line Transmitter – DA
4
3.3 About the TP-112HD
Your Kramer TOOLS TP-112HD XGA/HD Line Transmitter - DA:
• Receives a computer graphics 1
/HD
2
signal and transmits it over two
CAT 5 cables to appropriate receivers
3
• Has a transmission range of more than 300 ft. (more than 100 meters)
• Includes the Power Connect feature
• Is 12V DC fed
3.4 Recommendations for Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables 4
to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables).
• Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer product
away from moisture, excessive sunlight and dust
4 Your TP-112HD XGA/HD Line Transmitter – DA
Figure 1 , Figure 2 , Figure 3 and Table 1 define the TP-112HD:
1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on a 15-pin HD connector
having a resolution from VGA up to UXGA
2 The TP-112HD accepts high definition resolutions: 480p, 576p, 720p, 1080i, and 1080p
3 Note that the CAT 5 connectors exclude audio
4 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
