Technical Specifications

9

6 Technical Specifications

Table 3 includes the technical specifications:

Table 3: Technical Specifications

1

of the VM-9T

INPUTS:

1 looping composite video 1 Vpp/75 on a BNC connector
1 looping stereo audio +4dBm, on RCA connectors

OUTPUTS:

2 composite video 1 Vpp/75 on BNC connectors
2 stereo audio +4dBm, on RCA connectors

1 CAT5 on an RJ-45 connector

MAX. OUTPUT LEVEL:

VIDEO: 2.4Vpp

AUDIO: +21dBm

BANDWIDTH (-3dB):

VIDEO: 350MHz

AUDIO: 43kHz

DIFF. GAIN:

0.04%

DIFF. PHASE:

0.06 Deg.

K-FACTOR:

<0.05%

S/N RATIO:

76MHz

CROSSTALK (all hostile): –67dB
CONTROLS:

VIDEO: Level: –0.4dB to +6dB

EQ.: 0dB to +10dB @ 50MHz

AUDIO: Level: –12dB to +12dB

COUPLING:

VIDEO: DC

AUDIO: AC

AUDIO THD + NOISE:

0.02%

AUDIO 2nd HARMONIC:

0.005%

POWER SOURCE:

100-240 VAC, 50/60Hz 12 VA

DIMENSIONS:

21.46cm x 16.25cm x 4.36cm (8.45” x 6.39” x 1.72”, W, D, H

WEIGHT:

1.4 kg (3.3 lbs.) approx.

ACCESSORIES:

Power cord

1 Specifications are subject to change without notice
