Getting Started
KRAMER ELECTRONICS, LTD.
2
The package includes the following items:
VM-42 Video Switcher - Distributor
Power cord
This user manual
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
3 Overview
The unique and versatile VM-42 Video Switcher - Distributor combines the
functions of a composite video switcher and a distribution amplifier. The
VM-42 Video Switcher - Distributor is a 4x1 vertical interval switcher, with
each of the 4 inputs also operating as a 1:2 distribution amplifier.
The
VM-42 Video Switcher - Distributor is linkable in any of the following
combinations:
4 x 1 Switcher
1 x 1:8 DA
4 x 1:2 DA
2 x 1:4 DA
1 x 1:6 + 1 x 1:2 DA
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality and positioning your VM-42 Video Switcher
- Distributor in a location free from moisture and away from excessive
sunlight and dust
4 Your Video Switcher - Distributor
Figure 1 and Tables 1 and 2 define the VM-42 Video Switcher – Distributor:
