4.3
Your VM-50HN Headphone Distributor
Figure 3: VM-50HN Headphone Distributor
Table 3: VM-50HN Headphone Distributor
#
Feature
Function
1
INPUT 6.5mm phone connector
Connects to the input source
2
OUT 6.5mm phone connectors
Connect to the headphones (1 to 5)
3
12V DC Connector
Connects to the 12V DC power supply
4
POWER LED
Illuminates when the unit is ON
5
LEVEL CONTROL Potentiometers
Adjust
6
the audio signal output level (OUT 1 to OUT 5)
MONO Pushbutton
Press IN for mono audio, leave OUT for stereo audio
1 Rotate to adjust the appropriate level
