Your VM-28H / VM-216H

9

4.1 Using the IR Transmitter

You can use the RC-IR2 IR transmitter to control the machine via the built-in
IR receiver on the front panel or, instead, via an optional external IR
receiver

1

. The external IR receiver can be located 15 meters away from the

machine. This distance can be extended to up to 60 meters when used with
three extension cables

2

Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert the internal IR connection cable

.

3

Connect the external IR receiver to the REMOTE IR 3.5mm connector.

























1 Model: C-A35M/IRR-50

2 Model: C-A35M/A35F-50

3 P/N: 505-70434010-S
