KRAMER: SIMPLE CREATIVE TECHNOLOGY
The 105V, 1:5 High Resolution Video DA
18
8.2 Technical Specifications
Table 11 includes the technical specifications 1
Table 11: Technical Specifications of the 105V 1:5 High Resolution Video DA
:
INPUT: 1 video, 1Vpp/75 Ω on an RCA connector
OUTPUTS: 5 video, 1Vpp/75 Ω on RCA connectors
MAX. VIDEO OUTPUT: 2Vpp
VIDEO BANDWIDTH (-3dB): 400MHz
DIFF. GAIN: 0.1%
DIFF. PHASE: 0.15Deg.
K-FACTOR: <0.05%
S/N RATIO: 75dB
CONTROL: Up to +6dB
COUPLING: AC
POWER SOURCE: 12V DC, 100mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H
WEIGHT: 0.28kg (0.62lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-3T 19" rack adapter
1 Specifications are subject to change without notice
