Your 104M, 1:4 Microphone Amplifier
9
9
5.2 Technical Specifications
Table 4 includes the technical specifications 1
Table 4: Technical Specifications of the 104M 1:4 Microphone Amplifier
:
INPUT: One mono microphone 5mVpp/10k Ω on a 6.5mm phone connector
OUTPUTS: 4 mono line level 1Vpp/150Ω on 6.5mm phone connectors
MAX. OUTPUT LEVEL: 4.8Vpp
AUDIO BANDWIDTH (-3dB): 37kHz
GAIN CONTROL: 5dB to 54dB
S/N RATIO: 78dB
THD @1kHz: 0.1%
POWER SOURCE: 12V DC, 20mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H
WEIGHT: 0.28kg (0.62lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-3T 19" Rack adapter
1 Specifications are subject to change without notice
