The CGLS Digital Overhead
„Dura-Drive™‟ is a versatile direct-drive agitator for cell culture
and most aseptic mixing applications. The Dura-
Drive™ is designed to eliminate the problem
of a magnetic agitator decoupling often observed in large volume mixing over 3L and the
stirring of solutions with viscosities greater than water.
The Dura-
Drive™ features a brushless, maintenance-free DC motor with drive assemblies
designed for quiet operation. The units are powered by a 24 VDC power supply (included).
Specifications:
Speed Range: 5-150 rpm
Dimensions (HxWxD):
8 x 4.5 x 6.5” (20 x 12 x 17cm) including handle
Weight: 4.3 lb (2.0 kg)
Rating: CLS-1440-100/E, 24VDC fused at 1 amp
Features:
Forward and Reverse modes
Locking Speed Control Knob
Brushless DC
“maintenance free” Motor
Attached Handle for easy transportation
Locking Input power cord
Unpack your stirrer carefully. Be certain to retain the warranty information, all packing material
and instruction manual. Claims for damages require that packing material be retained for
inspection.
All damage claims must be initiated with the delivering carrier within five (5) days of
receipt of the product.
The Power Supply MUST be attached to unit BEFORE plugging the AC end into the
supply outlet.
1. Dura-Drive
™ is shipped complete and ready for operation. With the unit
turned off (rocker switch in the center position), insert and screw the DC (round) end of the
supplied power cord set
into the rear jack of the unit (indicated as “24VDC”). Plug the opposite
(AC) end into any appropriate outlet (one providing power at the rated voltage and frequency).
2. Position the unit over the drive stem. Align the four grommets with the pegs on the drive
stem. Rotate the shaft at the top of the drive stem to align the pin with the groove in the drive
fork. Press down until all four grommets are securely seated.
General Description
Unpacking Instructions
Operating Instructions
