Configuration Module (ACC-02) Page 6 Version 1.00
8/31/2007
3 How To Use
The configuration module currently is used with the IMD23 or IMDE23 unit. Soon,
other units can be used with this as well.
1. Power Off the power supply and Opto Supply and disconnect or power off any
step, direction, and disable/enable signals. If using the internal opto supply,
disconnect it.
2. Set all the DIP switches on the Config Module to the required positions
3. Connect the Config Module to the unit being set, by using the provided
cable.
4. Power On the MAIN Power Supply but not the Opto Supply
5. Press and HOLD the black button on the Config Module (S3). When Black
button is pressed and held the GREEN LED on the Config Module should
light. This indicates that the settings have been stored.
6. Power Off everything.
7. Disconnect the Config Module from the device being set.
8. Reconnect all signals or power on all signals
9. Power On the Power Supply and Opto Supply. (The new settings are now in
effect)
