Configuration Module (ACC-02) Page 11 Version 1.00
8/31/2007
Direction Sense
This is similar to the “step sense” feature where the direction of rotation can change
upon seeing the rising edge of a signal or the falling edge of a signal.
The switch has two options:
ON: Changes direction on a rising edge signal (looks for a low to high transition)
OFF: Changes direction on a falling edge signal (looks for a high to low transition)
