Comfort-Aire HCG**V1E Series - Manual (Page 31)

31
Table 12. Control Board Operation - Continued
CONTROL SIGNAL & MODE OPERATION TOTAL KW BOARD ACTION
W1, W2 & Y/Y2
AUX HEAT
ON
5 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
10 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
15 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 30 seconds delay
20 KW
Stage 1 Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
Stage 4 Heat on after 15 seconds delay
25 KW
Stage 1Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
Stage 4 Heat on after 15 seconds delay
Stage 5 Heat on after 20 seconds delay
30 KW
Stage 1Heat on instantly
Cool blower on after 3 second delay
Stage 2 Heat on after 5 seconds delay
Stage 3 Heat on after 10 seconds delay
Stage 4 Heat on after 15 seconds delay
Stage 5 Heat on after 20 seconds delay
Stage 6 Heat on after 25 seconds delay
OFF
Heat stages off instantly
Heat blower turns off after 40 second delay
G
FAN
On Fan blower on after 3 second delay
Off Fan blower off instantly
Y/Y2
HEAT PUMP & COOL
On Cool blower on after 3 second delay
Off Cool blower off after 40 second delay
Y1
HEAT PUMP & COOL
On Cool blower on after 3 second delay
Off Cool blower off after 40 second delay
Y1 & Y/Y2
HEAT PUMP & COOL
On Cool blower on after 3 second delay
Off Cool blower off after 40 second delay
