Comfort-Aire HCG**V1E Series - Manual (Page 22)

22
HCG24V1E
&
HCG30V1E
Cooling Airflow Heating Airflow
A/B Switch Setting
0 = OFF, 1 = ON
COOL Switch Setting
0 = OFF, 1 = ON
Airflow
(CFM)
A/B Switch Setting
0 = OFF, 1 = ON
Heater Kit
Installed (KW)
Airflow
(CFM)
5 6 7 8
0 0 0 0 0 525 0 0 600
0 0 0 0 1 560 0 5 800
0 0 0 1 0 600 0 8 1000
0 0 0 1 1 625 0 10 1000
0 0 1 0 0 700 0 15 1300
0 0 1 0 1 750 0 20 n/a
0 0 1 1 0 800 0 25 n/a
0 0 1 1 1 850 0 30 n/a
0 1 0 0 0 875
0 1 0 0 1 890
0 1 0 1 0 930
0 1 0 1 1 950
0 1 1 0 0 1000
0 1 1 0 1 1050
0 1 1 1 0 1125
0 1 1 1 1 1200
HCG36V1E
&
HCG42V1E
Cooling Airflow Heating Airflow
A/B Switch Setting
0 = OFF, 1 = ON
COOL Switch Setting
0 = OFF, 1 = ON
Airflow
(CFM)
A/B Switch Setting
0 = OFF, 1 = ON
Heater Kit
Installed (KW)
Airflow
(CFM)
5 6 7 8
1 0 0 0 0 525 1 0 700
1 0 0 0 1 560 1 5 900
1 0 0 1 0 600 1 8 1100
1 0 0 1 1 650 1 10 1100
1 0 1 0 0 700 1 15 1300
1 0 1 0 1 750 1 20 1500
1 0 1 1 0 800 1 25 n/a
1 0 1 1 1 850 1 30 n/a
1 1 0 0 0 875
1 1 0 0 1 950
1 1 0 1 0 1050
1 1 0 1 1 1150
1 1 1 0 0 1250
1 1 1 0 1 1350
1 1 1 1 0 1400
1 1 1 1 1 1600
HCG48V1E
&
HCG60V1E
Cooling Airflow Heating Airflow
A/B Switch Setting
(* = either 0 or 1)
COOL Switch Setting
0 = OFF, 1 = ON
Airflow
(CFM)
A/B Switch Setting
(* = either 0 or 1)
Heater Kit
Installed (KW)
Airflow
(CFM)
5 6 7 8
* 0 0 0 0 1100 * 0 800
* 0 0 0 1 1200 * 5 1000
* 0 0 1 0 1250 * 8 1200
* 0 0 1 1 1300 * 10 1200
* 0 1 0 0 1350 * 15 1400
* 0 1 0 1 1400 * 20 1600
* 0 1 1 0 1450 * 25 1800
* 0 1 1 1 1500 * 30 2000
* 1 0 0 0 1550
NOTES:
• Airflow values listed are for 240V operation. For
208V operation, multiply the CFM value by .95 for
HCG24V1E, HCG30V1E, HCG36V1E, & HCG42V1E units.
For HCG48V1E & HCG60V1E units, mulitply the CMF value
by .90.
• When matched with two-stage outdoor units the airflow on
low (Y1 or W1) input only will be 70% of the values shown in
this table.
* 1 0 0 1 1600
* 1 0 1 0 1650
* 1 0 1 1 1700
* 1 1 0 0 1750
* 1 1 0 1 1800
* 1 1 1 0 1900
* 1 1 1 1 2000
Table 9. Airflow Data for HCG**V1E Air Handlers
