56
SECTION XI
REPLACEMENT PARTS LIST
NOTE: The above illustration may not depict your particular dryer exactly. This illustration is a
composite of the various dryer models. Be sure to check the descriptions of the parts
thoroughly before ordering.
Replacement Parts For Phase 3
Illus. No. Part No. Qty. Description
1 112526 1 Phase 3 Coin Keyboard (touch pad) Label
2 800040 1 Control Panel ONLY
800087 1 Phase 3 Coin Control Panel Complete (Less Acceptor)
3* 865460 1 25¢ Single Coin Optic Acceptor
865476 1 10¢/25¢ Dual Coin Optic Acceptor
4 137075 1 Phase 3 Coin Controller
5 152001 4 #8-32 Hex Nut
6 137020 1 15-Pin Connector ONLY
7 137021 15 Microprocessor Socket
8 137022 1 Strain Relief
9 150301 1 #8-18 x 7/16” Phillips TEK Screw
* Consult ADC factory for coin acceptors not listed.
