53
D. AUTOMATIC/MANUAL PROGRAM SELECTABLE
(“MANUAL” SELECTED, NON-REVERSING DRYERS)
Dip switch settings - Switch #1 - open
Switch #2 - closed
Switch #3 - closed
Switch #4 - open
Switch #5 - open
Switch #6 - unimportant
Switch #7 - unimportant
Switch #8 - unimportant
1. Display shows “FILL.”
2. Enter manual selection, press MAN 1 .
3. Display shows “Ld_.”
4. Enter drying time (1 through 99 minutes).
5. Press “Enter/Start.”
6. Display shows “LC_.”
7. Enter cooling time (1 through 99 minutes).
8. Press “Enter/Start.”
9. Display shows “F_.”
10. Enter fabric (Temp) (1 through 9).
11. Press “Enter/Start.”
12. Display shows “dr and drying time entered,” display will then count down until selected time reaches zero.
13. Display shows “CL and cool down time entered,” display will then count down until selected time reaches
zero.
14. At the end of the cooling cycle, an audible tone will sound, and the display will show “CC00” meaning cycle
is complete. Door must now be opened to cancel display.
E. MICROPROCESSOR REVERSING DRYER
1. For dryers equipped with reversing option, dryer will always have reversing action if dip switch #1 is in the
open position.
2. For dryers equipped with reversing option and programmed for reverse action selectability, (dip switch #1
is in the closed position).
