GB - 23
13. Insert new friction disc assembly into frame.
Install washers onto carrier bearing and slide into
speed selector arm.
14. Slide hex shaft through new friction plate
assembly. Install pinion gear and washer onto
hex shaft and slide shaft into right bearing.
15. Install left bearing using hardware removed in
step 7.
16. Reinstall clip pin into hex shaft.
17. Connect pivot pin to speed selector arm. See
Speed Selector Adjustment on page 17.
18. Install bottom cover.
19. Reinstall wheels.
20. Return unit to upright position.
21. Connect spark plug wire to spark plug.
22. Adjust traction drive clutch. See Traction Drive
Clutch Adjustment on page 21.
SHORT TERM
IMPORTANT: NEVER spray unit with high pressure
water or store unit outdoors.
Run with attachment clutch engaged a few minutes
after each use to free unit of any loose or melting snow.
Close fuel shut-off valve.
Inspect unit for visible signs of wear, breakage or
damage.
Keep all nuts, bolts and screws properly tightened and
know unit is in safe working condition.
Store unit in a cool, dry protected area.
LONG TERM
Clean unit thoroughly with mild soap and low pressure
water and lubricate (see MAINTENANCE on page 14).
Touch up all scratched painted surfaces.
Remove weight from wheels by putting blocks under
frame or axle.
Fuel System
Gasoline left in the fuel system for extended periods
without a stabilizer will deteriorate, resulting in gum
deposits in the system. These deposits can damage
the carburetor and the fuel hoses, filter and tank.
Prevent deposits from forming in the fuel system during
storage by adding a quality fuel stabilizer to the fuel.
Follow the recommended mix ratio found on the fuel
stabilizer container.
To treat the fuel system for storage:
1. Add fuel stabilizer according to manufacturers’s
instructions.
2. Run engine for at least 10 minutes after adding
stabilizer to allow it to reach the carburetor.
NEVER store the engine with fuel in the fuel tank inside
of a building with potential sources of ignition.
STORAGE
WARNING: AVOID INJURY. Read and
understand the entire Safety section before
proceeding.
SERVICE PARTS
Order the following parts through your Dealer:
Part No. Description
00036800 Ariens Hi-Temp Grease (3, 3 oz. cartridges)
21533500 Spark Plug
07200327 Impeller Belt
07200101 Traction Belt
53200500 Shear Bolts
00170800 Friction Disc
ACCESSORIES
See your authorized Ariens dealer to add the additional
accessories available to your Sno-Thro.
Part No. Description
73203100 Slicer Bar
72200600 120 Volt Starter Kit
72406500 Front Weight Kit
