Optional Painting Instructions
Painting:
1. Apply two even coats of adhesion promoter to flares.
Allow recommended flash time between coats. Let second
coat dry for 15 minutes before primer application.
2. Apply an even coat of primer to flare surface. (A high
build primer is recommended)
3. Paint flares with a automotive grade paint. (A flex
additive must be added to paint)
Page 3 of 3
11620.10
NOTICE: Do not use any harsh chemicals on flares. Use only plastic approved cleaning chemicals.
Pain Preparation:
1. Lightly sand flares with 320 grid sandpaper.
2. Remove all surface contaminants from flares using an
approved grease and wax remover.
3. Wipe flares with a tack rag to remove any dust or dirt.
JK All-Terrain Flat Fender Flare Kit
6/30/10 SB
8. Install the rear flares by lining the holes in the flare up with the holes in
the rear fenders. In the top 2 hole locations, hand tighten 2 M6 bolts, flat
washers and flange nuts to secure the rear flares. Insert plastic push rivets into
the remaining hole locations. Once all the push rivets are installed, go back
and tighten the M6 bolts. NOTE: If installing JK Wheel Liners (P/N 11620.50),
it is only necessary to install the top 2 bolts at this point. Please refer to the
Wheel Liner instructions to complete rear flare installation.
