11025.04 – 11026.04 JK Wrangler Mirror Relocation Kit
Installation Instructions
Step 6:Insert the mirror into the new relocation bracket as
shown in . Start the torx head bolt that was removed in step 1.
Tighten the bolt so that the mirror is snug but still movable inside
of the mirror relocation bracket. Open the door and adjust the
mirror parallel to the door or when there is no contact with the
door. After the mirror has been repositioned, tighten the bolt until
the breakaway feature works.
Caution: DO NOT OVERTIGHTEN The mirror head base is
made of aluminum and can easily be stripped.
Please note: Due to production changes made in late 2008 it is required that a plastic insert be used
when installing the mirror head into the mirror relocation bracket. The plastic inserts account for a
reduction made in the mirror head mounting shaft taper size. Late 2008 shafts are 2mm smaller than
earlier 2007-2008 Jeep® JK Wranglers. Inserts are required for proper fitment and operation of
mirrors. After insertion of the insert, refer to step 6 for proper installation of the mirror head.
NOTE: To ease installation of the mirror head the insert can be cut into two separate
halves.
Step 7: Repeat steps 1-6 for the opposite side.
