Rugged Ridge Mirror Relocation Brackets, Black, 07-14 Jeep Wrangler (JK) User Manual
Page 2
11025.04 – 11026.04 JK Wrangler Mirror Relocation Kit
Installation Instructions
Step 3: Remove the front 2 torx head bolts from the
windshield retainer bracket.
(DO NOT DISCARD THESE BOLTS Both these bolts will be
reused to install the mirror relocation bracket in step 4.
Step 1: Using a #40 torx head bit or socket, unscrew the
torx head bolt located under the head of the factory mirror.
DO NOT DISCARD THIS BOLT
It will be reused later for reassembly. Remove the mirror
head.
NOTE: Some force may be needed to remove the mirror
head from the bracket. Carefully work the mirror head
from side to side until it is free.
Step 2: With the mirror head removed, open the front door
and lower the window. Working through the window using
the same #40 torx, remove the 2 bolts located on the
inside in front of the door panel. Hold the mirror bracket to
keep it from falling and damaging the door or paint.
DO NOT DISCARD THESE BOLTS These will be reused
for installation of the door filler plates.
2
