Rugged Ridge Half Doors, Front, 07-14 Jeep Wrangler (JK) - Manual

Page 1 of 4
Contents: QTY
1. Half Door (2)
2. Door Hinge (4)
3. M8 Countersunk Bolt (8)
4. M8 Bolt (4)
5. M8 Flat Washer (4)
6. Logo (2)
7. Grab Handle (not shown) (2)
8. Grab Handle Mount Plate (not shown) (4)
9. M6 Bolt (not shown) (4)
10. Nylon Door Strap (not shown) (2)
JK FRONT HALF DOORS
11509.01 JK Front Half Doors
2. Disconnect wiring harness before removing door. Release
the red locking tab and pull down on the connector. Next, remove
the strap from the hook located inside the vehicle. NOTICE! Door
can swing freely once the strap is released potentially causing
damage to your vehicle. Do not let go of door when strap is
disconnected.
1. Remove factory mirrors if intended to reuse on Half Doors.
Remove (2) torx head bolts and separate mirror from the door. Set
mirror aside. NOTE: Do not use factory mirrors for 2011 and up
Wranglers equipped with power mirrors. For 2011 and up Wranglers,
or for added convenience for any JK, Rugged Ridge replacement
mirrors are recommended (part number 11002.21).
This product is intended to provide added “off-road” convenience and utility to your vehicle.
This product is not intended to provide occupant containment or protection in the event of an accident or roll-
over. Further, “on road” use may involve increased risk of serious injury in the event of side-impact accidents. To
reduce risk from these types of injuries: Always wear seat belt and shoulder harness for all vehicle occupants.
Keep arms and body inside vehicle. Drive safely, read and understand all manufacturers warnings and product
instructions before installation.
1
6
3
2
5
4
