Rugged Ridge Cold Air Intake Kit, 3.6L, 12-14 Jeep Wrangler User Manual
Page 3
Page 3 of 3
6. Secure air tube to rubber isolator. Loosen all hose clamps to allow for movement of tube. Place 2.5"
Hose clamp over aluminum air tube. Install air filter through heat shield opening. Secure 2.5” clamp.
7. With tube secured to heat shield and filter installed tighten all hose clamps. reconnect breather tube
back onto intake tube. Two small hose clamps have been provided to insure a tight fit to intake tube.
Attach weather stripping to top of heat shield. Cut to fit.
8. Double check all hose clamps to insure there are no air leaks before driving.
Secure tube to heat shield
Install filter to intake tube
Secure hose clamps
Connect breather hose with clamp
Install weather stripping
© Copyright 2009, Omix-Ada
Omix-Ada Inc.
460 Horizon Dr. Suite 400
Suwanee, Georgia 30024
Note: This filter is polyester synthetic and never needs to be oiled. It can de cleaned with warm
water and mild detergent dish soap.
9. Install hose clamps to radiator overflow hose. Reusing bolts removed in step (#3) attach to radiator.
Replace engine cover.
