97-06 TJ - LJ STEERING SKID PLATE
Page 2 of 2
Rugged Ridge Limited Warranty
Applies to Rugged Ridge Products by OMIX-ADA Inc.
Please find warranty card supplied with product for more information. Warranty card
should be filled out and returned to address listed below.
OMIX-ADA Inc.
460 Horizon Dr. Suite 400
Suwanee, Georgia 30024
18003.12
6. With skid plate mounted drill hole in front
frame cross member as shown. A 13/32"
bit should be used.
7. Insert M10 hex nut - Rod through the
drivers side opening in the frame cross
member.
8. Install M10 x 30 hex bolt and M10 lock
washer though skid plate and frame cross
member and tighten to M10 hex nut-rod.
9. Tighten the lower bumper and lower
frame to 65 ft-lbs and the cross member
bolt to 20 ft-lbs.
WARNING:
Never Fasten Steering Skid plate in a location that will damage or interfere with electrical wires,
brake lines, steering mechanisms or any other related objects. Damage to steering system, brake and or eletrical
system may occur if installed wrong. Instructions must be followed and all bolts and fasteners tightened to
specified torque.
