Rugged Ridge Steering Box Skid Plate, 97-06 Jeep Wrangler (TJ) User Manual
06 tj - lj steering skid plate
97-06 TJ - LJ STEERING SKID PLATE
Page 1 of 2
18003.12
1. TJ -LJ Steering Skid Plate (1)
2. M10 x 30 Hex Head Bolt (1)
3. M10 Lock Washer (1)
4. M10 Hex Nut with Rod (1)
2. Remove lower drivers side mounting bolt from
bumper. DO NOT DISCARD. Hardware to be
reused.
3. Remove the lower steering box mounting bolt
DO NOT DISCARD. Hardware to be reused.
4. Place skid plate in location to line up with
the lower bumper mount and the lower
side frame mount.
1. Position skid plate up to the steering box with the front flange over lower bumper mounting bolt. make
sure the lower side mounting hole lines up with bolts in steering box.
NOTE: This skid plate is designed to be used with the stock bumper. Some aftermarket bumpers
may require modification.
5. Secure to bumper and frame using hardware
removed in steps 2 & 3.
