Appendix a: general specifications – AMT Datasouth 400 User Manual
Page 69

User's Guide 69
Appendix A: GENERAL SPECIFICATIONS
Note: The FM402TT does not support the PAL
TM
Print and Program Language but is included here for reference
only.
Specification
FM402TT
FM412TT
FM403TT
Print method
Direct thermal and thermal transfer
Resolution
203 DPI
(8 dots/mm)
203 DPI
(8 dots/mm)
300 DPI
(12 dots/mm)
Maximum print
width
4.2 in. (107 mm)
4.10 in. (104 mm)
Maximum print
length
43 in. (1090 mm)
**
80 in. (2032 mm)
54 in. (1371 mm)
**
Maximum print
speed
3 inches (76.2 mm) per second
2 inches (50.8 mm)
per second
Onboard RAM
512 K bytes
2 M bytes
2 M bytes
Media
type
Direct thermal: Paper, vinyl, visible light and infrared
scannable label, tag stock, butt cut or die cut, with various
adhesives.II.
hThermal transfer: Paper or vinyl labels and tags, butt cut or
die cut, with various adhesives.
Maximum label
roll diameter
4 in.(102mm) outside diameter, 1 in.(25.4mm) inside
diameter
Label indexing
Black stripe and gap
Ribbon types
Wax, Wax/resin and Resin
Ribbon size
OD 1.45 in. (37 mm); ID 0.5 in. (12.7mm)
Interface
RS-232 serial and Centronics parallel ports, with auto polling
Dimension
W7.3 in. x D10.9 in. x H6.0 in.
(W186 mm x D278 mm x H153mm)
Weight
1.9 kg (4.1 lbs.)
FCC class B
FCC class A
Electrical
CE, UL and CUL approved. Input 19 VAC or 24 VDC
(min. 2.5 A), 50/60 Hz
Operating
temperature
40
°
to 140
°
F (5
°
to 38
°
C)
Storage
temperature
-40
°
to 140
°
F (-40
°
to 60
°
C)
Humidity
15 to 85% RH
Windows driver
Win, 95, 98, 2000, XP and NT
Printer emulation
PPLA, PPLB
PAL, Text, Display, Hex
Rotation
0
o
, 90
o
, 180
o
and 270
o
, 4 direction rotations
