User's Guide 18
Loading the Ribbon
Thermal Transfer Media only
If Direct Thermal Media is used, skip to the section Loading Media.
1. Open the Media Access Cover by lifting it up until it rests in the vertical position.
2. Slide the two Print Head Latches toward the back of the printer to unlock the print head
module.
Figure 8 – Print Head Latches
Print Head Latch
Print Head Latch
Media Access Cover
