Maintenance
Accessory and Replacement Parts List
NOTE: This is a partial parts list for parts not shown here, call MagiKitch’n or a MagiKitch’n service representative.
Always give the Model and Serial Numbers of your unit when ordering parts and accessories.
Item Description
1 Top grid
2 Radiant
3 Burner
4 Burner clip
5 Baffle, right side
6 Baffle, left side
7 Outer side
8 Inner side (right)
9 Inner side (left)
10 Drip cup
11 Outer back
12 Inner back
13 Rear support angle
14 Rear burner support
15 Water tub
16 Grease trough
17 Towel bar
18 Lower shelf
19 Upper shelf
20 Base assembly
21 Upper shelf
22 Inlet manifold
23 Runner tube
24 Inner front assembly
25 90° elbow with clip
Item Description
26 Valve (push to turn)
27 Pressure tap orifice
28 Heat shield
29
30 Manifold, weld assembly
31 Outer front
32 Knob
33 Grease trough
34 Service shelf
35 Service shelf support
36 Thermocouple (not shown)
37 Thermocouple bracket (not shown)
38
39
40
41 ½” NPT Jam nut
42 ½” FNPT Shut off valve
43 ½” NPT nipple
44 ¾” MNPT x ½” FNPT adaptor
45 180° return elbow
46 ¾” close nipple
47 Safety pilot valve
48 Runner supply tube
49
1-01-12962 rev B L25-004 rev 1 (05/11) 10
