G50
© 2008 AS America Inc.
7144.803/804/805 Top Mount
7143.803/804 Undercounter Mount
NOTES:
* COUNTERTOP CUTOUT 800 x 521mm WITH 19mm RADIUS
(31-1/2" x 20-1/2" WITH 3/4’ RADIUS) AT CORNERS.
STRAINERS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL AND
COUNTERTOP SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the
range of tolerances established by ASME Standard A112.19.4
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided leaflet.
12-1/4"
(311mm)
33"
(838mm)
4" (102mm)
4" (102mm)
4" (102mm)
4"
(102mm)
22"
(559mm)
* CUTOUT
NOTE
2-1/4"
(57mm)
7144.804
4 HOLE
7144.805
5 HOLE
F
IN
IS
H
E
D
W
A
LL
O
R
S
P
LA
S
H
B
A
C
K
38mm (1-1/2)
DIA. (TYP.)
OPTIONAL
COUNTER TOP (BY OTHERS)
C/L
15-5/8"
(397mm)
FINISHED
FLOOR
3-1/2"
(89mm)
CLAMPING DETAIL
LUG AND
SCREW
ASSEMBLY
COUNTERTOP
13/16"
(21mm)
MAX.
16-1/2"
(419mm)
1-1/2" O.D. TAILPIECE
36" (914mm)
SUGGESTED
6"
(152mm)
1/2"
(13mm)
6-3/4"
(171mm)
1-1/2"
(38mm) R.
CLAMPING DETAIL
LUG AND
SCREW
ASSEMBLY
COUNTERTOP
12-1/2"
(318mm)
7143.804
4 HOLE
F
IN
IS
H
E
D
W
A
L
L
O
R
S
P
L
A
S
H
B
A
C
K
C/L
OPTIONAL
COUNTER TOP (BY OTHERS)
FINISHED
FLOOR
* CUTOUT
NOTE
13/16"
(21mm)
MAX.
1-1/2" O.D.
TAILPIECE
36" (914mm)
SUGGESTED
6"
(152mm)
1/2"
(13mm)
6-3/4"
(171mm)
12-1/4"
(311mm)
22"
(559mm)
2-1/4"
(57mm) 3-1/2"
(89mm)
1-1/2"
(38mm) R.
4" (102mm)
4" (102mm)
4" (102mm)
38mm (1-1/2)
DIA. (TYP.)
25"
(635mm)
NOTES:
* COUNTERTOP CUTOUT 597 x 521mm WITH 19mm RADIUS
(23-1/2" x 20-1/2" WITH 3/4’ RADIUS) AT CORNERS.
● Recommended minimum countertop thickness:
Wood - 19mm (3/4")
Marble and Solid Surface - 12mm (1/2")
STRAINERS NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL AND
COUNTERTOP SUPPORTS.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the
range of tolerances established by ASME Standard A112.19.4
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided leaflet.
DOUBLE BOWL SINK
SINGLE BOWL SINK
ENAMELED STEEL
Revised 2/08
