DAILY MAINTENANCE

REPLACING SQUEEGEE RUBBER BARS

If the squeegee blades are worn out and do not dry properly,
change the drying side as follows:
Pull the squeegee assembly out as illustrated under
“PREPARATION OF THE MACHINE”
Unlock the clamp (1) between the two rear blades
Pull out the blades (2/3) and the rubber bar (4)
Flip the rubber blade or, if necessary, replace it
Adjust squeegee height as illustrated under “HEIGHT
ADJUSTMENT OF THE SQUEEGEE SUPPORT” at chapter
“PREPARATION OF THE MACHINE”
Reassemble it all by following the above procedure in reverse

RELEASING THE DISC BRUSH

1. Turn the key to “OFF” and remove it from the instrument board.

(releasing the brush when the machine is on may cause serious
injury)

2. Disconnect the battery connector
3. Lift the brush head

4. Keeping the brush head lifted, rotate the brush to release it

from the brush holder plate as illustrated in the picture.

CLEANING THE FILTER AND THE SOLUTION TANK

Close the solution tap:
1. Unscrew the solution filter to empty the tank
2. Remove the cartridge and clean it
Reassemble it all by following the above procedure the other way
round
