CONTROLS
MAIN CONTROLS
1. Horn
2. Digital hourmeter
3. Battery level indicator
4. On/Off key switch
5. Forward/reverse switch
6. Forward/reverse levers
7. Solution lever
8. Squeegee control pedal: the
squeegee is working when the
pedal is lifted.
9. Pedal for right wheel directional
lock.
10. Brush control pedal, the brush is
working when the pedal is lifted.
11. Pedal for left wheel directional
lock.
12. Button to de-activate the vacuum motor.
2
1
4
5
3
6
7
9
8
10
11
10
