Page 7
GRP
CH
BAND
L
ANT
MHz ACT
RF
AF
SQ
BA
EQ
1
14
2
4
5
7
8
9
13
12 11
10
3
6
ADD
GRP
CH
BAND
L
ANT
MHz ACT
RF
AF
SQ
BA
ADD
EQ
Receiver VFD Interface
All information displays on the same VFD screen.
Parameter Lock Icon
(Can be turned on or off)
4
Group (Can be programmed)
2
RF Signal Meter (Indicates received signal strength)
6
Frequency Band (Indication only)
1
Working Frequency (Mhz.)
13
Encryption Status Icon (Can be turned on or off)
5
Squelch Meter (Settings can be programmed)
9
ACT Indicator
11
Channel (Can be programmed)
3
Audio Signal Meter (Indicates audio input level from transmitter)
7
Transmitter Battery Meter (Shows real-time battery status)
8
Equaliser (Can be programmed)
10
Diversity A/B Antenna Signal Indicators
(For antenna setup only)
12
Address Code (For remote control ID. Can be programmed)
14
Fully-Lit VFD Screen
8
9
Press the rotary controller knob to activate and move the cursor to any of the 8 parameters. Each
press moves the cursor to the next parameter. The selected parameter cursor begins to flash when
activated. Rotate the rotary controller whilst flashing to change a parameter value.
8
SQ
GRP
CH
EQ
ADD
ANT
L
Function Selection
Rotary Controller: To set parameter values
8 parameters can be selected and programmed. See instructions below:
Parameter Setting Procedures
To Activate Parameters
Rotate the rotary controller knob clockwise to increase or counterclockwise to decrease the parameter
values.
To Change Parameters
The parameter changes will be saved manually if the rotary controller is pressed after adjusting. The
cursor stops flashing after the rotary controller is pressed to confirm the change.
To Save Changed Parameters Manually
The parameter changes will be saved automatically if the rotary controller is not pressed for
approximately 5 seconds. The cursor also stops flashing after 5 seconds.
To Save Changed Parameters Automatically
