36
GB Technical data and specifi cations
GAS BURNERS (injectors and fl ow-rates)
Cat.: see nameplate on cover; Class 1 or 2.
Type “X” cooker
ELECTRIC HOTPLATES
ø 145
1,0 kW - Normal hotplate
1,5 kW - Rapid hotplate
ø 180 1,5 kW - Normal hotplate
2,0 kW - Rapid hotplate
HEATING ELEMENT POWERS
bottom element
1.5 kW
top element 0.7 kW
grill 2.0 kW
oven light 15 W
TOTAL ELECTRIC OVEN POWER
static oven
2.21 kW
EQUIPMENT
All models are equipped with safety device
for oven and grill burners.
Depending on the models, cooker may
also have:
- Oven thermostat
- Electric oven lighting
- Grill burner or element
- One or more electric hotplates
For the LAYOUT OF HOB BURNERS see
the models illustrated in fi gure 1 at the
back of this manual.
For the ELECTRIC WIRING DIAGRAM
see fi gure 2 at the back of this manual.
The electrical power is stated on the na-
meplate visible inside the warming com-
partment (if present) or on the back of the
cooker.
A copy of the nameplate is glued to the co-
ver of this manual (for gas or gas-electric
products only).
Nominal external
dimensions Cookers
55x55
Height at hob
Height with lid raised
Height with glass lid
Depth with door closed
Depth with door open
Width cm. 85
cm. 137
cm. 137,3
cm. 54
cm. 100
cm. 54
Usable
dimensions
Oven
Width
Depth
Height
Volume cm. 39,5
cm. 43,0
cm. 32,0
l. 54
Gas Burner Inye-
ctor
Low
fl ow-rate
(kW)
Nominal
fl ow-rate
(kW)
G20
20
mbar auxiliar
semi-rap.
rapid
oven
grill 77
97
123
130
110
0,40
0,40
0,85
1,00 1,00
1,65
2,80
3,00
2,00
G30
28-30
mbar
G31
37
mbar auxiliar
semi-rap.
rapid
oven
grill 50
65
83
86
70 0,40
0,40
0,85
1,00 1,00
1,65
2,80
3,00
2,00
