1411 s, Odel, Umber – Decolav 1411 User Manual
Page 5: Eries
Customer Service
561-274-2110
www.decolav.com
i
nstallation
i
nstructions
M
odel
N
uMber
: 1411 S
erieS
5
• STEP #5
o
NOTE: WASTE SYSTEM SHOWN, DECOLAV
®
9100 DECORATIVE BOTTLE TRAP, IS A RECOMMENDED ACCESSORY AND NOT
INCLUDED!
o Install Waste System according to manufacturer’s installation instructions.
o Refer to Figure #3.
• STEP #6
o Install faucet and water supply according to manufacturer’s installation instructions.
o
NOTE: FAUCET AND WATER SUPPLY NOT INCLUDED!
o Check for leakage.
Waste System
Figure #3
Bottle Trap
Wall Cover
Horizontal Leg
Slip Joint Nut
Washer
Slip Joint Nut
Washer
