Decolav 1411 - Manual (Page 4)

Figure #2
Drain
Thick Washer
Drain Nut
Tailpiece
Lavatory
Countertop
Tailpiece
Drain
Thick Washer
Drain Nut
Apply Plumber's Putty
or Caulking here
Figure #1
Customer Service
561-274-2110
www.decolav.com
i
nstallation
i
nstructions
M
odel
N
uMber
: 1411 S
erieS
4
• STEP #3
o Apply Plumber’s Putty or Caulking around the underside of rim near the edge as shown.
o Carefully lower
Lavatory in place, align, and press firmly.
o Wipe off excess sealant.
o Refer to Figure #1.
o
NOTE: ALLOW SEALANT TO SET BEFORE PROCEEDING!
• STEP #4
o NOTE: DRAIN SHOWN, DECOLAV ® 9290 UMBRELLA DRAIN, IS A RECOMMENDED ACCESORY AND NOT INCLUDED!
o Install Drain according to manufacturer’s installation instructions.
o
NOTE: DO NOT OVERTIGHTEN DRAIN!
o Refer to Figure #2.
